The idea of Smart Studio is to provide a studio solution that is both on air and in production. Both studios are networked, so the production studio can be used as an over-the-air backup via a mute detector and pass-through switch. The all-in-one automation station for 24 / 24 programs includes all the modules needed to operate one or more radios: playout, broadcast, business planning, recording, editing and post-production.
| Size | XS | S | M | L |
|---|---|---|---|---|
| Euro | 32/34 | 36 | 38 | 40 |
| USA | 0/2 | 4 | 6 | 8 |
| Bust(in) | 31-32 | 33 | 34 | 36 |
| Bust(cm) | 80.5-82.5 | 84.5 | 87 | 92 |
| Waist(in) | 24-25 | 26 | 27 | 29 |
| Waist(cm) | 62.5-64.5 | 66.5 | 69 | 74 |
| Hips(in) | 34-35 | 36 | 37 | 39 |
| Hips(cm) | 87.5-89.5 | 91.5 | 94 | 99 |
With your arms relaxed at your sides, measure around the fullest part of your chest.
Measure around the narrowest part of your natural waist, generally around the belly button. To ensure a comfortable fit, keep one finger between the measuring tape and your body.
STUDIO PRODUCTION
AKG K72: Dynamic headphones, 200 mW, 16 to 20,000 Hz, 112 dB SPL / V, 32 Ohm, 3 m cable length, stereo plug - 3.5 mm (1/8 inch) with 6.3 mm (1/4 " ) screw - on adapter, matte black finish, net weight 200 g
AKG P220: Studio cardioid condenser microphone, cardioid condenser element, Spider non-slip suspension, low frequency attenuation, 20dB buffer.
ALCATEL TEMPORIS 180: Black phone with incoming call indicator light, Last number redial, Wall mount, Message waiting indicator, Earpiece volume adjustable: 5 levels.
Chair for Broadcast Desk, technicians and/or guests.
TK MIC ARM: Adjustable microphone desk arm
DM M16: FRAME Modular professional broadcast mixer 16-12 channels, 4 microphone/line input modules with equalization, 4 line/line input modules with equalization, 2 hybrid phones with equalization and echo cancellation. Talkback, Out: Master , 2 X SUB, REC, Monitor
DM ON AIR LIGHT: professional lighting for diffusion systems. Laser cut polycarbonate graphic panel. RJ45 connection, operating voltage and output 12 Vdc. Current 330 mA. Input voltage 100-240Vac. Product dimensions: W 38,3 cm D 4,2 cm H 13,5 cm 1 Kg.
DM VIBE 3: 3-band audio processor with built-in RDS encoder and stereo generator. Graphic display, incremental encoder. Stereo separation 60 dB from 30 to 15 kHz, RDS 25 PS, 25 radiotext (64 characters), 24 AF lists. Inputs: SCA, analogue on white XLR.
GSM gateway: , dual band 900/1800 MHz, high quality audio. Incl. external antenna.
MILLENIUM HP4: 4x independent stereo inputs with unbalanced jacks; Separate volume control for each channel; Easily expandable - Up to 4 devices can be used together; Internal shielded dual regulated power supply with voltage selector for 115V / 60Hz or 230V / 50Hz; 19", 1 U
ACER: Acer 23.6" TN Full HD 1920x1080 Display LED Monitor, 5 ms, 1000: 1, 300 cd / m2, I / O DVI port.VGA DVI-D HDMI
Diffusion desk with scratch-resistant surface, 15U side rack, cylindrical legs, incl. 23U Rack (8U + 15U)
PRESONUS ERIS 5: Pair of active studio monitors, LF driver: 4.5" (114 mm) Kevlar, HF driver: 1" (25 mm) silk dome, frequency response: 70 Hz - 20 kHz, cutoff frequency: 2.8 kHz, LF amplifier power: 25 W speaker, peak SPL (at 1 meter): 100 dB, input impedance: 10 kOhm
STUDIO PRODUCTION PREFILE: including: cables, connectors, interconnects and factory test.
1500 VA 10 'Autonomy, 3x12V 9Ah. ON-Line double conversion technology, wide input range, programmable output sockets, LCD display, 50/60 Hz converter function, EPO (emergency stop) function, automatic/manual bypass. 2U rack.
WS with Standard SW Playout, library and import, playlist, adv. management, run scheduler, audio editing, flash player and rec. PC 4U RK - Win 64 bit i5 8 GB RAM HD SO 250 GB 2X2 TB HD. Sound Card 4 stereo XLR OUT Bal. XLR 4 stereo XLR IN Bal. with cable
